This effect is known as isotopic fractionation. At higher temperatures, CO 2 has poor solubility in water, which means there is less CO 2 available for the photosynthetic reactions. The enrichment of bone 13 C also implies that excreted material is depleted in 13 C relative to the diet. The carbon exchange between atmospheric CO 2 and carbonate at the ocean surface is also subject to fractionation, with 14 C in the atmosphere more likely than 12 C to dissolve in the ocean.
This increase in 14 C concentration almost exactly cancels out the decrease caused by the upwelling of water containing old, and hence 14 C depleted, carbon from the deep ocean, so that direct measurements of 14 C radiation are similar to measurements for the rest of the biosphere.
Correcting for isotopic fractionation, as is done for all radiocarbon dates to allow comparison between results from different parts of the biosphere, gives an apparent age of about years for ocean surface water. The CO 2 in the atmosphere transfers to the ocean by dissolving in the surface water as carbonate and bicarbonate ions; at the same time the carbonate ions in the water are returning to the air as CO 2. The deepest parts of the ocean mix very slowly with the surface waters, and the mixing is uneven.
The main mechanism that brings deep water to the surface is upwelling, which is more common in regions closer to the equator.
Navigation menu
Upwelling is also influenced by factors such as the topography of the local ocean bottom and coastlines, the climate, and wind patterns. Overall, the mixing of deep and surface waters takes far longer than the mixing of atmospheric CO 2 with the surface waters, and as a result water from some deep ocean areas has an apparent radiocarbon age of several thousand years. Upwelling mixes this "old" water with the surface water, giving the surface water an apparent age of about several hundred years after correcting for fractionation.
The northern and southern hemispheres have atmospheric circulation systems that are sufficiently independent of each other that there is a noticeable time lag in mixing between the two. Since the surface ocean is depleted in 14 C because of the marine effect, 14 C is removed from the southern atmosphere more quickly than in the north. For example, rivers that pass over limestone , which is mostly composed of calcium carbonate , will acquire carbonate ions. Similarly, groundwater can contain carbon derived from the rocks through which it has passed.
Volcanic eruptions eject large amounts of carbon into the air. Dormant volcanoes can also emit aged carbon. Any addition of carbon to a sample of a different age will cause the measured date to be inaccurate. Contamination with modern carbon causes a sample to appear to be younger than it really is: Samples for dating need to be converted into a form suitable for measuring the 14 C content; this can mean conversion to gaseous, liquid, or solid form, depending on the measurement technique to be used.
Before this can be done, the sample must be treated to remove any contamination and any unwanted constituents. Particularly for older samples, it may be useful to enrich the amount of 14 C in the sample before testing.
Radiocarbon Dating
This can be done with a thermal diffusion column. Once contamination has been removed, samples must be converted to a form suitable for the measuring technology to be used. For accelerator mass spectrometry , solid graphite targets are the most common, although gaseous CO 2 can also be used. The quantity of material needed for testing depends on the sample type and the technology being used. There are two types of testing technology: For beta counters, a sample weighing at least 10 grams 0. For decades after Libby performed the first radiocarbon dating experiments, the only way to measure the 14 C in a sample was to detect the radioactive decay of individual carbon atoms.
Libby's first detector was a Geiger counter of his own design. He converted the carbon in his sample to lamp black soot and coated the inner surface of a cylinder with it. This cylinder was inserted into the counter in such a way that the counting wire was inside the sample cylinder, in order that there should be no material between the sample and the wire. Libby's method was soon superseded by gas proportional counters , which were less affected by bomb carbon the additional 14 C created by nuclear weapons testing.
These counters record bursts of ionization caused by the beta particles emitted by the decaying 14 C atoms; the bursts are proportional to the energy of the particle, so other sources of ionization, such as background radiation, can be identified and ignored. The counters are surrounded by lead or steel shielding, to eliminate background radiation and to reduce the incidence of cosmic rays.
In addition, anticoincidence detectors are used; these record events outside the counter, and any event recorded simultaneously both inside and outside the counter is regarded as an extraneous event and ignored. The other common technology used for measuring 14 C activity is liquid scintillation counting, which was invented in , but which had to wait until the early s, when efficient methods of benzene synthesis were developed, to become competitive with gas counting; after liquid counters became the more common technology choice for newly constructed dating laboratories.
The counters work by detecting flashes of light caused by the beta particles emitted by 14 C as they interact with a fluorescing agent added to the benzene. Like gas counters, liquid scintillation counters require shielding and anticoincidence counters. For both the gas proportional counter and liquid scintillation counter, what is measured is the number of beta particles detected in a given time period. This provides a value for the background radiation, which must be subtracted from the measured activity of the sample being dated to get the activity attributable solely to that sample's 14 C.
In addition, a sample with a standard activity is measured, to provide a baseline for comparison. The ions are accelerated and passed through a stripper, which removes several electrons so that the ions emerge with a positive charge. A particle detector then records the number of ions detected in the 14 C stream, but since the volume of 12 C and 13 C , needed for calibration is too great for individual ion detection, counts are determined by measuring the electric current created in a Faraday cup. Any 14 C signal from the machine background blank is likely to be caused either by beams of ions that have not followed the expected path inside the detector, or by carbon hydrides such as 12 CH 2 or 13 CH.
A 14 C signal from the process blank measures the amount of contamination introduced during the preparation of the sample. These measurements are used in the subsequent calculation of the age of the sample. The calculations to be performed on the measurements taken depend on the technology used, since beta counters measure the sample's radioactivity whereas AMS determines the ratio of the three different carbon isotopes in the sample. To determine the age of a sample whose activity has been measured by beta counting, the ratio of its activity to the activity of the standard must be found.
To determine this, a blank sample of old, or dead, carbon is measured, and a sample of known activity is measured. The additional samples allow errors such as background radiation and systematic errors in the laboratory setup to be detected and corrected for.
What is Radiocarbon Dating?
The results from AMS testing are in the form of ratios of 12 C , 13 C , and 14 C , which are used to calculate Fm, the "fraction modern". Both beta counting and AMS results have to be corrected for fractionation. The calculation uses 8,, the mean-life derived from Libby's half-life of 5, years, not 8,, the mean-life derived from the more accurate modern value of 5, years. The reliability of the results can be improved by lengthening the testing time. Radiocarbon dating is generally limited to dating samples no more than 50, years old, as samples older than that have insufficient 14 C to be measurable.
Older dates have been obtained by using special sample preparation techniques, large samples, and very long measurement times. These techniques can allow measurement of dates up to 60, and in some cases up to 75, years before the present. This was demonstrated in by an experiment run by the British Museum radiocarbon laboratory, in which weekly measurements were taken on the same sample for six months.
The measurements included one with a range from about to about years ago, and another with a range from about to about Errors in procedure can also lead to errors in the results. The calculations given above produce dates in radiocarbon years: To produce a curve that can be used to relate calendar years to radiocarbon years, a sequence of securely dated samples is needed which can be tested to determine their radiocarbon age. The study of tree rings led to the first such sequence: These factors affect all trees in an area, so examining tree-ring sequences from old wood allows the identification of overlapping sequences.
In this way, an uninterrupted sequence of tree rings can be extended far into the past. The first such published sequence, based on bristlecone pine tree rings, was created by Wesley Ferguson. Suess said he drew the line showing the wiggles by "cosmic schwung ", by which he meant that the variations were caused by extraterrestrial forces.
It was unclear for some time whether the wiggles were real or not, but they are now well-established. A calibration curve is used by taking the radiocarbon date reported by a laboratory, and reading across from that date on the vertical axis of the graph.
Radioactivity : Radiocarbon Dating
The point where this horizontal line intersects the curve will give the calendar age of the sample on the horizontal axis. This is the reverse of the way the curve is constructed: Over the next thirty years many calibration curves were published using a variety of methods and statistical approaches. The improvements to these curves are based on new data gathered from tree rings, varves , coral , plant macrofossils , speleothems , and foraminifera. The INTCAL13 data includes separate curves for the northern and southern hemispheres, as they differ systematically because of the hemisphere effect.
The southern curve SHCAL13 is based on independent data where possible, and derived from the northern curve by adding the average offset for the southern hemisphere where no direct data was available. The sequence can be compared to the calibration curve and the best match to the sequence established.
